| Specifications: |
|
| Model Number |
DHIPD60/28LRG/30-D-V5 |
| Image Sensor |
1/1.8″ CMOS |
| Effective Pixels |
3288 (H) × 1850 (V) |
| ROM |
256 MB |
| RAM |
2 G |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.0005 Lux@F1.0 (Colour, 30IRE)
0.0004 Lux@F1.0 (B/W, 30IRE)
0 lux (Illuminator on) |
| S/N Ratio |
＞56 dB |
| Illumination Distance |
30 m (98.43 ft) (IR)
30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control |
Auto / Manual |
| Illuminator Number |
2 (Multi-core (IR + warm) light) |
| Pan/ Tilt/ Rotation Range |
Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Lens |
|
| Lens Type |
Fixed focal |
| Mount Type |
M16 |
| Focal Length |
2.8mm |
| Field of View |
H: 109°; V: 59°; D: 131° |
| Iris Type |
Fixed |
| Max Aperture |
F1.0 |
| Close Focus Distance |
2 m (6.56 ft) |
| DORI Distance |
Detect: 70.2 m(230.31 ft)
Observe: 28.1 m (92.19 ft)
Recognise: 14.0 m (45.93 ft)
Identify: 7.0 m(22.97 ft) |
| Intelligence |
|
| IVS (Perimeter Protection) |
Intrusion, tripwire (the two functions support the classification
and accurate detection of Humans and Vehicles) |
| SMD 4.0 |
Less false alarm, longer detection distance. |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search,
event extraction and merging to event videos |
| AcuPick |
Uses deep learning algorithms and works with back-end
devices to accurately match targets, such as people and
motor vehicles, and search through live and recorded videos
to quickly locate targets. |
| AI SSA |
Adopt deep learning algorithms to adjust the parameters of
the image to suit the conditions. |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search,
event extraction and merging to event videos |
| Video |
|
| Compression |
H.265; H.264; H.264H; H.264B; MJPEG
(only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265 (Compression rate ≥25%)
AI H.264 (Compression rate ≥25%) |
| Video Frame Rate |
Main stream: 3288 × 1850@(1 fps–25/30 fps)
Sub stream: 1920 × 1080@(1–25/30 fps)
Third stream: 1920 × 1080@(1–25/30 fps)
*The values above are the max. frame rates of each stream;
for multiple streams, the values will be subjected to the total
encoding capacity. |
| Streaming Capability |
3 Streams |
| Resolution |
6M (3288 × 1850/3200 × 1800); 4M (2688 × 1520/2560 × 1440);
3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720);
D1 (704 × 576/704 × 480); VGA (640 × 480);
CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR / VBR / ABR |
| Video Bit Rate |
H.264: 3 kbps–16384 kbps; H.265: 3 kbps–16384 kbps |
| Day/Night |
Auto (ICR)/Colour/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual / regional custom |
| Gain Control |
Auto |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Smart Dual Light |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520
resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| LDC |
Yes |
| Audio |
|
| Built-in MIC |
Yes, built-in dual Mic |
| Built-in Speaker |
Yes, built-in dual Speaker |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm |
|
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection;
IP conflict; illegal access; motion detection; video tampering;
tripwire; intrusion; scene changing; audio detection; intensity
change; voltage detection; external alarm; SMD; security
exception |
| Network |
|
| Ethernet |
RJ-45 (10/100Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption;Firmware encryption;Configuration encryption;
Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;
Generation and importing of X.509 certification;syslog;
HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP;
SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP;
NFS; PPPoE; SNMP; P2P |
| Interoperability |
ONVIF (Profile S; Profile G;Profile T); CGI |
| Max. User Access |
20 (Total bandwidth: 64 M) |
| Storage |
FTP;SFTP; Micro SD card (support max. 512 GB); NAS |
| Web Viewer |
IE: IE11; Chrome ; Firefox |
| Management Software |
Smart PSS Lite; DMSS |
| Smart Phone |
iOS; Android |
| Certification |
|
| Certification |
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Port |
|
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: wet contact, 5 mA 3–5 VDC |
| Alarm Output |
1 channel out: wet contact, 300 mA 12 VDC |
| Power |
|
| Power Supply |
12 VDC; PoE |
| Dual Power Backup |
When the power adapter and PoE provide power at the same
time, disconnect one of them. The device will continue to work,
but will not restart. |
| Power Consumption |
Basic: 4.1 W (12 VDC); 6 W (PoE)
Max. (H.265+WDR+ warm light+siren and light active deterrence
+ intelligence on): 8.2 W (12 VDC); 10 W (PoE) |
| Environment |
|
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95% |
| Protection |
IP67 |
| Structure |
|
| Casing Material |
Metal |
| Product Dimensions |
Φ122.0 mm × 116.1 mm (4.80″ × Φ4.57″) |
| Net weight |
0.8 kg (1.76 lb) |
| Gross Weight |
1.0 kg (2.20 lb) |
