SPRO 6MP IP Turret with COLOUR NIGHT 2.0 and Built-In Mic (ECONOMY)

SPRO 6MP IP Turret with COLOUR NIGHT 2.0 and Built-In Mic (ECONOMY)

Name: SPRO 6MP IP Turret with COLOUR NIGHT 2.0 and Built-In Mic (ECONOMY)
SKU: DHIPD60/28LRW-M-E
Availability: InStock

~~£95.00 £95.00 Ex VAT~~ £85.50 £85.50 Ex VAT

SKU: DHIPD60/28LRW-M-E Categories: CCTV Cameras, IP Cameras

Description

Spread the love

The SPRO 6MP ColourNight 2.0 Camera offers high-definition imaging with its 1/2.7″ CMOS sensor, providing clear visuals even in low light conditions. It supports output resolutions of up to 6 MP (3200 × 1800) at 20 fps, and 2688 × 1520 at 25/30 fps, using an H.265 codec for high compression and ultra-low bit rates. Featuring built-in Multi-core Light, it ensures effective IR and warm light illumination up to 30 meters. The camera incorporates a built-in microphone, 12 VDC/PoE power supply, IP67-rated protection, and support for human detection, ensuring easy installation and reliable performance in diverse environments.

Key Features:

• 1/2.7″ CMOS image sensor, low luminance, and high definition image.
• Outputs max. 6 MP (3200 × 1800) @20 fps, and supports 2688 × 1520@25/30 fps.
• H.265 codec, high compression rate, ultra-low bit rate.
• Built-in Multi-core Light, the max. IR distance is 30 m and the
max.warm light distance is 30 m.
• ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments.
• Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking,
applicable to various monitoring scenes.
• Built in Microphone.
• 12 VDC/PoE power supply, easy for installation.
• IP67 protection.
• Supports human detection (SMD).

Specifications:
Model Number	DHIPD60/28LRW-M-E
Image Sensor	1/2.7” CMOS
Max. Resolution	3200 (H) × 1800 (V)
ROM	128 MB
RAM	256 MB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual 1/3 s-1/100,000s
Min. Illumination	0.007 lux@F1.6 (Colour, 30 IRE); 0.0007 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
S/N Ratio	＞56 dB
Illumination Distance	30 m (98.43 ft) (IR); 30 m (98.43 ft) (Warm light)
Illuminator On/Off Control	Auto/ Manual
Illuminator Number	1 (Multi-core (IR + warm light)
Pan/Tilt/Rotation Range	Horizontal: 0°–360°, Vertical: 0°–78°, Rotation: 0°–360°
Lens
Lens Type	Fixed-focal
Mount Type	M12
Focal Length	2.8mm
Max. Aperture	F1.6
Field of View	H:110°; V:58°; D: 132°
Iris Type	Fixed
Close Focus Distance	1.1m (3.61 ft)
DORI Distance	Detect: 63.6m (208.66 ft) Observe: 25.4m (93.33 ft) Recognise: 12.7m (41.67 ft) Identify: 6.4m (21.00 ft)
Intelligence
Human Detection	Support the classification and accurate detection of human
Smart Search	Work together with smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression	H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec	Smart H.265+: Smart H.264+
Video Frame Rate	Main stream: 3200 × 1800@(1–20 fps)/2688 × 1520@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability	2 Streams
Resolution	6M (3200 × 1800); 4M (2880 × 1620/2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control	VBR; CBR
Video Bit Rate	H.264: 32 kbps–8192 kbps; H.265: 12 kbps–8192 kbps
Day/Night	Auto(ICR) / Colour/ B/W
BLC	Yes
HLC	Yes
WDR	DWDR
White Balance	Auto; natural; street lamp; outdoor; manual; regional; custom
Gain Control	Auto/ Manual
Noise Reduction	3D NR
Motion Detection	Off / On (4 Areas, rectangular)
Region of Interest (RoI)	Yes (4 areas)
Image Rotation	0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Smart Illumination	Yes
Smart Dual Light	Yes
Mirror	Yes
Privacy Masking	4 Areas
Audio
Built-in MIC	Yes
Audio Compression	G.711a; G.711Mu; PCM; G.726
Alarm
Alarm Event	Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception
Network
Network	RJ-45 (10/100Base-T)
SDK and API	Yes
Network Protocol	IPv4; IPv6; HTTP; TCP;UDP; ARP; RTP; RTCP; RTMP; SMTP; FTP DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
Interoperability	ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone;
User/Host	20 ( Total bandwidth: 48M)
Storage	FTP
Browser	IE, Chrome, Firefox
Management Software	Smart PSS Lite; DMSS
Mobile Phone	iOS & Android
Cyber Security	Video Encryption; Configuration; Encryption; Digest; WSSE; Account lockout; Security logs; Generation and importing of X.509 certification; HTTPS; Trusted boot; Trusted execution; Trusted upgrade
Certification
Certifications	CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
General
Power Supply	12VDC/PoE (802.3af)
Power Consumption	Basic: 2 W (12 VDC), 2.9 W (PoE); Max. : 4 W (12 VDC); 5.3 W (PoE) (H.265 + intelligence on+ DWDR + illuminator intensity)
Operating Temperature	–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity	≤95%(RH), non-condensing
Storage Temperature	-40ºC ~ +60ºC (-40ºF ~ +140ºF)/ ≤95% RH
Storage Humidity	≤95%(RH), non-condensing
Protection	IP67
Casing Material	Metal
Dimensions	85.6 mm × Φ94.0 mm (3.37″ × Φ3.7″)
Net Weight	0.34 kg (0.75 lb)
Gross Weight	0.45 kg (0.99 lb)
